SpeedoHealer Wiring

A SpeedoHealer wiring harness is always required to allow the vehicle's speed signal to pass through to the SpeedoHealer module for correction.

INDICATE YOUR BIKE'S MODEL AND YEAR

For most bikes, a "Plug n' Go" wiring harness is available that has the same original style connectors as the vehicle, so a SpeedoHealer module can be connected to the speed sensor without cutting or splicing any original wires or requiring any additional power connections. In almost all cases, the SpeedoHealer module can use the power and ground provided by the ECU to the speed sensor.

However, if the vehicle has an uncommon connector style or if the wire carrying the speed signal is part of the main ECU wiring harness (such as on bikes with ABS), it would be necessary to cut the correct wire and use a universal wiring harness to bypass the signal through to the SpeedoHealer module. Universal cables include cable ties with high quality 3M gel.
